高精度緊湊型微歐姆計

PROMET SE－高精度、緊湊型微歐姆計
PROMET SE 是一款緊湊、電池供電的歐姆計，具備最高可調 200 A 的測試電流。配備兩組電流輸出與兩組電壓量測輸入，可同時於兩個量測點進行電阻測定。

透過電池操作所帶來的高度靈活性，以及 PROMET 產品系列一貫的高功能性與高精度，使此款通用型微歐姆計特別適合於變電站或工業環境中的可攜式應用。

• 特別適合嚴苛環境
• 可於兩個量測點進行電阻測定
• 最高 200 A 的恆定測試電流
• 用於評估連接品質
• 具備溫度補償之量測功能
• 可整合於 ACTAS 斷路器測試系統
• 可對最多 6 個主接點進行動態電阻量測
• 操作簡單直覺
• 可透過電腦進行結果管理與測試報告輸出

 一般說明
 高精度歐姆計，具備最高 200 A 的可調測試電流。本量測裝置內建可充電電池，適合於變電站與工業環境中的可攜式應用。兩組電流輸出與兩組電壓量測輸入，可於兩個量測點同時量測電阻。搭配 ACTAS 測試系統使用時，可針對每極 2 個主接點室進行靜態與動態主接點電阻量測。


量測功能
2 組電阻量測
品質因數判定
匯流排模式（BusBar mode）
具溫度補償之電阻量測
搭配 ACTAS 系統進行動態電阻量測（每極 2 個主接點）

System description PROMET SE - High-accuracy, compact micro-ohm meter
PROMET SE is a compact, battery-operated ohm meter with an adjustable test current of up to 200 A. Two current outputs and two voltage measurement inputs allow the resistance to be determined at two measurement points simultaneously.

Flexible handling with battery operation and the high functionality and precision which are characteristic of the popular PROMET product range make this universal micro-ohm meter particularly suitable for portable use in switching stations or industrial environments.

• Ideal for difficult conditions
• Determination of resistance at two measurement points
• Constant test currents up to 200 A
• Assessing the quality of connections
• Measurement with temperature compensation
• Integration in circuit breaker testing with ACTAS
• Dynamic resistance determination for up to six main contacts
• Simple and intuitive operation
• Results management and test report output via PC

General description
High-precision ohm meter with an adjustable test current of up to 200 A. The measuring device is equipped with a rechargeable battery for portable use in switching stations and industrial environments. Two current outputs and two voltage measurement inputs allow the resistance to be measured at two measurement points simultaneously. Used in combination with an ACTAS test system, static and dynamic determination of the main contact resistances is possible on 2 main contact chambers per pole.



Measurement functions
2 x resistance measurement
Determination of the quality factor
BusBar mode
Resistance measurement with temperature compensation
Dynamic resistance measurement with ACTAS systems 2 main contacts per pole)
