多通道直流電池測試系統

專用電池測試系統
IviCycle D1000 旨在成為高通道數電池應用的完美搭檔。IviCycle 提供每通道成本低、大批量測試解決方案和廣泛的數據存儲能力。

完整的解決方案
IviCycle 是一套多通道直流電池測試系統。一機箱最多可容納 4 個模組。您可以混合搭配不同的 IviCycle 模組，創建出一台客製化的單元，具有所需數量的不同符合性通道，並具有僅直流或 EIS 功能。

D1000 模組各有 8 個符合 ±1A/-0.2 至 +5V 的通道。模組僅提供直流版本（無 EIS）。 這表示可在所有通道上同時/平行進行直流測量。 IviCycle 內建 DataSecure 模組，可完全獨立於電腦儲存每個通道的所有資料。 這可確保在通訊中斷或電腦當機/更新時，測量仍可繼續，資料也不會遺失。 這為長時間、高吞吐量的測試提供了安心保證。 IviCycle 裝置內建於 19 吋機架安裝外殼中，可輕鬆整合至現有的儲存機架，或作為獨立的台式多通道系統。

安全性
儀器的最大電流或電位可由操作者定義。因此可以保護珍貴的樣品，防止不安全的情況發生。

資料安全與連線
IviCycle 配備整合式 DataSecure 模組：

• 資料獨立於電腦並可儲存在機上。
• 可連接多台電腦。

軟體
IviCycle 可透過 Ivium 自己的軟體 IviumSoft 控制。此軟體功能多樣且直覺，可進行儀器控制、資料管理與分析等。IviCycle 也可以由 LabVIEWTM、C++、Delphi 等軟體控制。每台儀器的標準配備包括全套軟體。

Dedicated battery test system
The IviCycle D1000 is designed to be your perfect partner for high channel-count battery applications. The IviCycle offers a low cost-per-channel, high volume testing solution and extensive data storage capability.

Complete solution
The IviCycle is a multi-channel DC battery test system. The channels are divided over 4 modules. It is possible to mix and match different IviCycle modules to create a custom-built instrument with the desired number of channels of varying compliance, and with DC only or EIS capability.

The D1000 modules each have 8 channels of ±1A/-0.2 to +5V compliance. The modules are available as DC versions only (no EIS). This means that simultaneous/parallel DC measurements are possible on all channels. The IviCycle has an integrated DataSecure module that stores all data for each channel completely independently from the computer. This ensures that if there is a communication loss or a computer crash/update, the measurement will continue and data will not be lost. This provides peace-of-mind for long duration, high throughput testing. The IviCycle unit is built into a 19inch rack mountable housing for easy incorporation into existing storage racks, or as a stand-alone bench-top multi-channel system.

Safety
The maximum current or potential of the instrument can be defined by the operator. Thus valuable samples may be protected, and unsafe situations prevented.

Data security & Connection
The IviCycle is equipped with an integrated DataSecure module:

• Data is stored on board independent of the computer.
• Connection of multiple PCs is possible

Software
The IviCycle is controlled via Ivium’s own software, IviumSoft. This versatile, yet intuitive software, allows instrument control, data management and analysis, etc. The IviCycle can also be controlled from LabVIEWTM, C++, Delphi, etc. A full suite of software is included as standard with each instrument.

• Control of separate channels individually
• All channels simultaneously
• Synchronous start
• Data from different channels plotted individually or in 1 single graph
