Room condition monitoring / On site multi sensor

型號:Type E03
  • Easy recalibration. Integrated memory for digital zero point and slope adjustment
  •
  • Cost saving. Replaceable filter protects against dust and dirt
  • Digital interface for communication with room condition monitor type 880
  • Safe and compact electrical connection through M12 connector
  • The digital multisensor type E03 simultaneously records ambient temperature, relative humidity and absolute pressure at one measuring point.

    Even in environments with an extreme vibration load, the robust design enables long service lives.

    With excellent accuracy over the entire measuring range, the sensor provides reliable measured values with outstanding long-term stability and repeatability.

  • Technical data
    Type On site multi sensor for humidity, temperature and pressure
    Measuring range
    g Humidity
    g Temperature
    g Pressure
      0…100 % RH
    -40…85 °C 40...185 °F
    300…1200 mbar abs.
    Measuring medium ambient air
    (non-aggressive gases)
    Sensor length 75 mm 2.953“
    Sensor diameter 10 mm 0.394“
    Process connection without
    Nominal pressure n.a. (atmospheric pressure)
    Medium temperature -40…85 °C -40...185 °F
    Ambient temperature -40…85 °C -40...185 °F
    Storage temperature -40…85 °C -40...185 °F
    Degree of protection EN 60529 IP40
