Zurich Instruments > 鎖相放大器

四通道 PID/PLL 控制器選配件-用於600 MHz鎖相放大器

Quad PID/PLL Controller Option 型號：UHF-PID

產品特點產品規格 Features Specifications

配置	4 個具有PLL 功能的PID 控制器
PID 輸入參數	解調器1 至8 的X、Y、R 和Theta，輔助輸入1 和2，輔助輸出1 至 4
PID 輸出參數	信號輸出1 和2 的幅值，信號輸出偏置，振盪器1 至8 的頻率，輔助輸出1 至 4
PID 頻寬	可達300 kHz
PID 最小傳輸時延	1.5 µs（信號輸入到信號輸出）
PLL 頻率範圍	10 Hz - 600 MHz
PLL 頻寬	可達300 kHz

Introduction
The UHF-PID option consists of 4 configurable PID (proportional – integral – derivative) controllers. Seamlessly integrated with the UHFLI Lock-in Amplifier, the programmable PIDs feature in several applications including the setup of phase-locked loops (PLLs) for phase synchronization of two lasers, CEO stabilization, and fast AFM modes. The PID Advisor helps to identify suitable parameters, and displays step responses and transfer functions to support in-depth understanding of the experimental setup. Thanks to the Auto Tune feature, the loop filter settings are automatically adjusted to find the point with minimal residual PID error.

UHF-PID upgrade and compatibility
- Field-upgradeable option
- Compatible with all other UHF options
Applications
- Laser frequency stabilization
- Interferometer stabilization
- Optical phase-locked loops, e.g. carrier envelope offset stabilization (CEO)
- High-speed AFM, e.g. automatic gain control (AGC)
- MEMS characterization

Configuration	4 PID controllers with PLL capability
PID input parameters	X, Y, R, and Theta from demodulators 1 to 8, auxiliary inputs 1 and 2, auxiliary outputs 1 to 4
PID output parameters	Amplitude of signal outputs 1 and 2, signal output offsets, frequency of oscillators 1 to 8, auxiliary outputs 1 to 4
PID bandwidth	Up to 300 kHz
PID minimum propagation delay	1.5 µs (signal input to signal output)
PLL frequency range	10 Hz - 600 MHz
PLL bandwidth	Up to 300 kHz
