FroSyn Cooling Station

與溫度控制專家Julabo GmbH共同設計，能夠作為實驗室內傳統冰浴和乾冰浴的可持續替代品；FroSyn使用簡單，可以快速冷卻樣品並且與各種玻璃器皿相容。

FroSyn可與一組用於50 mL至500 mL圓底燒瓶的標準插件或與訂製的反應瓶固定板一起使用。對燒瓶插件使用砝碼和密封件或在樣品平板上使用惰性圓頂可防止在玻璃器皿上結冰。其他定製冷卻附件也可用於電池研發的4位固定模塊。

聯繫我們來獲取更多資訊並討論可用的選項！

主動溫度控制通過位於絕緣底板中的Pt100感測器能讓用戶設置自定義的冷卻板溫度（低至-70 °C）並防止溫度隨時間波動，從而實現出色的重現性和改進過的反應控制。與需要持續關注的乾冰冷卻浴不同的是，FroSyn穩定、受控且低於環境溫度的性能代表即使是夜間反應也可以完全放心的進行。
FroSyn上冷卻探頭和冷卻板周圍的專業絕緣提高了性能，保持設備不結冰，並有助於消除操作員在操作過程中被凍傷的可能性。
可選擇通過磁力攪拌板攪拌。

Designed in conjunction with temperature control specialists, Julabo GmbH, as a sustainable alternative to traditional ice and dry-ice baths within the laboratory; FroSyn enables rapid cooling of samples, is simple to use and is compatible with a wide range of glassware.

The FroSyn can be used with either a set of standard insets for round bottom flasks from 50 mL to 500 mL, or with custom manufactured reaction vial holding plates. The use of either weights and seals for the flask inserts or an inerting dome with the vial plates prevents the formation of ice on the glassware. Other custom cooling accessories are also available to compliment different applications, for example a 4-position holding module for battery research and development.

Get in touch for further information and to discuss the options available!

Active temperature control, via. a Pt100 sensor positioned in the insulated base plate, allows the user to set a defined plate temperature (down to -70 °C) and prevents temperature fluctuations over time – resulting in excellent reproducibility and improved reaction control. Unlike dry ice cooling baths that require constant attention, the stable and controlled sub-ambient performance of the FroSyn means that even overnight reactions can be performed with complete confidence.

Specialist insulation around the cooling probe and plate on the FroSyn improves performance, keeps the apparatus ice-free and helps eliminate the possibility of operator cold burns during operation.

Optional stirring via magnetic stirrer plate.
