IKA C-MAG HS 7 Control Magnetic Stirrer Hotplate

IKA’s stands strongly by its product and technology and is offering a lifetime warranty for this product – scientists can focus on their experiments using a reliable hotplate stirrer.
IKA not only focuses on hardened glass because of visibility, chemical resistance and safety, it also optically changes the game of a magnetic stirrer with a glass surface. The C-Mag HS 7 control improves over time with regular firmware updates – control of kinetics and sensitive reactions are supported by the integrated timer and counter function – the IKA SmartTemp® function protects user intelligently. PT1000 temperature sensor included.

Number of stirring positions	1
Stirring quantity max. per stirring position (H2O)	20 l
Motor rating output	9 W
Direction of rotation	right / left
Speed display set-value	LCD
Speed display actual-value	LCD
Speed control	Turning knob
Speed range	50 – 1500 rpm
Setting accuracy speed	10 rpm
Stirring bar length	30 – 80 mm
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h)	2 +K
Heat output	1000 W
Temperature display set-value	LCD
Temperature display actual-value	LCD
Temperature unit	°C
Heating temperature range	room temp. – 500 °C
Heat control	Turning knob
Temperature setting range	0 – 500 °C
Temperature setting resolution of heating plate	5 K
Connection for ext. temperature sensor	PT1000, ETS-D5, ETS-D6
Temperature setting resolution of medium	1 K
Adjustable safety circuit	100 – 650 °C
Set-up plate material	ceramic
Set-up plate dimensions	180 x 180 mm
Automatic reverse rotation	yes
Intermittend mode	yes
Viscosity trend measurement	yes
Timer	yes
Sensor in medium detection (Error 5)	yes
Temperature measure range PT1000	-10 – 400 °C
Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C)	2 ±%
Heating rate (1l H2O in H1500)	5 K/min
Heat control accuracy of heating plate (at 100°C)	5 ±K
Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C)	0.5 ±K
Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C)	0.5 ±K
Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C)	0.2 ±K
Dimensions (W x H x D)	220 x 88 x 354 mm
Weight	4 kg
Permissible ambient temperature	5 – 40 °C
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 21
RS 232 interface	yes
USB interface	yes
Voltage	220 – 230 / 115 / 100 V
Frequency	50/60 Hz
Power input	1020 W
Power input standby	2 W
