IKA EUROSTAR 60 Digital Overhead Stirrer

IKA EUROSTAR 60數位頂置攪拌器是一種强大的實驗室攪拌器，可攪拌40升（H<sub>2</sub>O）的水。它通過微處理器控制科技在0/30–2000 rpm的速度範圍內自動調整速度。安裝的安全電路可確保在防失速失效或超載條件下自動切斷。<br />
保持軸速度與所需速度的連續比較，並自動調整變化。這保證了即使樣品粘度發生變化，也能保持恒定的速度。

加入洽詢

產品特點產品規格 Features Specifications

主要功能包括：
- 數位速度顯示
- 無級調速
- 推進式攪拌器軸
- 超載保護
- 短期超載運行
- 薄型外殼
- 安靜操作
- 錯誤代碼顯示

Stirring quantity max. per stirring position (H2O)	40 l
Motor rating input	176 W
Motor rating output	126 W
Motor principle	Brushless DC
Speed display	7 segment LED
Speed range	0/30 – 2000 rpm
Viscosity max.	50000 mPas
Output max. at stirring shaft	126 W
Permissible ON time	100 %
Torque max. at stirring shaft	60 Ncm
Speed control	stepless
Setting accuracy speed	1 ±rpm
Deviation of speed measurement n > 300rpm	1 ±%
Deviation of speed measurement n < 300rpm	3 ±rpm
Stirring element fastening	chuck
Chuck range diameter	0.5 – 10 mm
Hollow shaft, inner diameter	11 mm
Hollow shaft (push-through – when stopped)	yes
Fastening on stand	extension arm
Extension arm diameter	16 mm
Extension arm length	220 mm
Speed control	electronic
Nominal torque	0.6 Nm
Housing material	alu-cast coating / thermoplastic polymer
Dimensions (W x H x D)	86 x 248 x 208 mm
Weight	4.4 kg
Permissible ambient temperature	5 – 40 °C
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 42
Voltage	230 / 115 / 100 V
Frequency	50/60 Hz
Power input	176 W

Key features include:
- Digital speed display
- Infinitely adjustable speed
- Push-through agitator shafts
- Overload protection
- Short-term overload operation
- Slim casing
- Quiet operation
- Error code display

Stirring quantity max. per stirring position (H2O)	40 l
Motor rating input	176 W
Motor rating output	126 W
Motor principle	Brushless DC
Speed display	7 segment LED
Speed range	0/30 – 2000 rpm
Viscosity max.	50000 mPas
Output max. at stirring shaft	126 W
Permissible ON time	100 %
Torque max. at stirring shaft	60 Ncm
Speed control	stepless
Setting accuracy speed	1 ±rpm
Deviation of speed measurement n > 300rpm	1 ±%
Deviation of speed measurement n < 300rpm	3 ±rpm
Stirring element fastening	chuck
Chuck range diameter	0.5 – 10 mm
Hollow shaft, inner diameter	11 mm
Hollow shaft (push-through – when stopped)	yes
Fastening on stand	extension arm
Extension arm diameter	16 mm
Extension arm length	220 mm
Speed control	electronic
Nominal torque	0.6 Nm
Housing material	alu-cast coating / thermoplastic polymer
Dimensions (W x H x D)	86 x 248 x 208 mm
Weight	4.4 kg
Permissible ambient temperature	5 – 40 °C
Permissible relative humidity	80 %
Protection class according to DIN EN 60529	IP 42
Voltage	230 / 115 / 100 V
Frequency	50/60 Hz
Power input	176 W
