IKA myPlate magnetic stirrer

The IKA myPlate combines the excellent technical features of the popular and proven IKA magnetic stirrers colour squid and big squid with the option of creative individualisation.
  • Personal interchangeable frame
    Design the set-up plate of the IKA myPlate by yourself. You receive the device with a decorative image template, that can be exchanged easily through the convenient interchangeable frame. Some people have family photos on their desk – you convert one of the best magnetic stirrers from your day-to-day lab work into a canvas for your favourite pictures.

    Proven high functionality
    Apart from stirring your samples with IKA myPlate on a creative surface, you get all good features of this strong stirrer, just as you are used to from IKA.

    • High chemical resistance
    • Electronically controlled motor
    • Digital speed indicator
    • Speed range between 100 and 2500 rpm
  • IKA offers generous free warranty extensions if you register your product at www.ika.com/register the warranty period. You can normally benefit from a year of additional services (2 + 1).

    Number of stirring positions 1
    Stirring quantity max. per stirring position (H2O) 1.5 l
    Motor rating output 2 W
    Direction of rotation left
    Speed display set-value LED
    Speed display actual-value LED
    Speed control Touch key
    Speed range 100 – 2500 rpm
    Setting accuracy speed 10 rpm
    Stirring bar length max. 30 mm
    Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h) 2 +K
    Set-up plate material glass
    Set-up plate dimensions Ø 135 mm
    Dimensions (W x H x D) 152 x 30 x 164 mm
    Weight 0.76 kg
    Permissible ambient temperature 5 – 40 °C
    Permissible relative humidity 80 %
    Protection class according to DIN EN 60529 IP 54
    Voltage 100 – 240 V
    Frequency 50/60 Hz
    Power input 4 W
    Power input standby 1 W
    DC Voltage 12 V=
    Current consumption 300 mA
