Electrolyser 608

Flow electrolyser with active area of 608 cm² and fluorinated components. Electrode zone 320 × 190 × 3.5 mm per half-cell. The cell is composed of insulated aluminium end plates, copper current collectors, and PVDF flow frames with fittings. Anode side comprises titanium sheet and mesh covered with a mixture of metal oxides (Ir, Ta), and plastic turbulizer. Cathode side comprises graphite-polymer bipolar plate. The cell is disassembled; corresponding bolts and nuts, five sets of fluoro-rubber sealings, and one extra turbulizer are included. Felt electrode for the cathode side, as well as membrane, is not included.
