Quadracell 4 position High Pressure Reactor

Designed to operate at temperatures up to 250 °C, the Quadracell has four cells, each with a volume of 10 mL, with material construction in your choice of either Stainless Steel 316, or Hastelloy C276 for enhanced chemical resistance if required.
The Quadracell is available to suit a maximum working pressure of 50 / 100 / 200 Bar and is supplied with a Pressure Release Valve, Pressure Gauge and 2 off Needle Valves (Stainless Steel UOS) as standard.
Designed, manufactured and tested in the UK, the Quadracell is incredibly robust and safe to use.  With a wide range of factory addition options like all of the Asynt high pressure reactors, you can tailor your Quadracell to suit your individual requirements – or choose an off-the-shelf model that’s ready to use right away.

• 4 x 10 mL cells
• Pressure rating of either 50/100/200 Bar
• Stainless Steel 316 build as standard
• Other materials available such as Hastelloy C276
• Heating & agitation via standard magnetic stirrer hotplate
• Additional accessories/options include:
  • Burst Disc Body
  • Set of three Burst Discs (One pre-assembled into Body, two supplied separately.
  • Vessel Seals (FKM, PTFE, EPDM, VMQ or FFKM)
  • 304L & 316L Stainless Steel over braided 1.5 metre hose
  • PTFE Lined flexible hose with Tube Stub fittings
  • Set of quick connect fittings 1/4″ size (1 stem and 1 body)
  • Spare Stem Packing Kit for Needle Valves
  • PTFE Liners
  • Hose Whip Checks
• Alternative means of temperature control and agitation available
• Installation & training available as an optional extra
